Frameset

Frame

Haro Double Peak 29" 6000 series alloy, w/ Internal housing

routing & Chainstay disc brake mount

Fork

SR Suntour XCT-30 29x100mm travel w/ hydraulic lockout

Colors

Electric Red

Drivetrain

Cranks

Shimano XCD-D114, 34/24T, 2x9-Spd

Pedals

FPD Nylon body, Crmo axles, Platform

Chain

KMC Z9 9-spd

Bottom Bracket

SR BB10-XCT Sealed cartridge

Front Derailleur

Shimano Alivio, FD-M4020-M, 2x9-spd, Top-Swing

Rear Derailleur

Shimano Acera 9-spd RD-M3000

Derailleur Shifter

Shimano Acera M3010, 2x9-spd

Freewheel/Cassette

Shimano HG-200 9-spd 11-36T

Wheels

Tires

Kenda Honey Badger XC 29 x 2.2

Wheels/Rims

Weinmann U-26 Disc alloy double wall

Braking System

Brakes

Shimano BR-MT200 hydraulic, 160mm Center Lock Rotors

Brake Levers

Shimano BL-MT200

Other Components

Grips/Tape

WTB Trail II

Handle Bar

Pivit alloy 15mm riser bar 31.8mm

Stem

Pivit forged stem, 31.8mm

Headset

1-1/8" Threadless for 50mm OD headtube, w/ 13mm Top cover

Saddle

Haro Double Peak

Seat Post

Pivit alloy micro adjust 31.6mm

Seat Clamp

Pivit alloy 34.9mm quick Release
