BMC 21 : Twostroke AL ONE
FULL
SPECIFICATIONS
|
SKU |
Twostroke AL ONE |
|
FRAME |
Twostroke 01 Premium Aluminium,
Hydroformed, Smoothwelded • Internal Cable Routing • BSA Threaded Bottom Bracket • Post Mount Disc |
|
FORK |
Rock Shox Recon RL Remote, 100mm
|
|
GEARS |
1x12 |
|
CHAINWHEEL |
SRAM NX Eagle 32T |
|
CASSETTE |
SRAM NX Eagle 11-50T |
|
CHAIN |
SRAM SX Eagle |
|
REAR DERAILLEUR |
SRAM NX Eagle |
|
SHIFTERS |
SRAM NX Eagle |
|
BRAKES |
Shimano Deore BR-M6100 / Shimano
SM-RT54 Rotors (160/160 S-M, 180/160 L-XL) |
|
HANDLEBAR |
BMC MFB03 750mm |
|
STEM |
Forged 6061 Alloy |
|
SADDLE |
Velo VL-1831 |
|
HUBS |
Shimano HB-MT400-B/FH-MT410-B |
|
RIMS |
Alex MD25, 25mm |
|
TIRES |
Vittoria Barzo 2.25 |
|
TIRE CLEARANCE |
58mm (measured width) |
|
WEIGHT (KG) |
12.8 |
|
ASTM CLASSIFICATION |
Level 3 |
GEOMETRY
| SIZE | S | M | L | XL |
| Rider Height CM | <170 | 170-182 | 180-192 | >190 |
| Top Tube MM (tt) | 597 | 618 | 638 | 658 |
| Wheelbase MM (wb) | 1112.5 | 1135 | 1161 | 1185 |
| Seat Angle (sa) | 75 | 75 | 75 | 75 |
| Seatpost Length MM | 350 | 400 | 400 | 400 |
| Stack MM | 588 | 598 | 608 | 623 |
| Trail MM (trail) | 109 | 109 | 109 | 109 |
| Rear Center MM (rc) | 425 | 425 | 425 | 425 |
| Reach MM (reach) | 422.5 | 445 | 465 | 485 |
| Head Tube MM (ht) | 87 | 93.5 | 106 | 122.5 |
| Head Angle (ha) | 67 | 67 | 67 | 67 |
| BB Drop MM (drop) | 64 | 64 | 64 | 64 |
| Stem Length MM | 60 | 60 | 60 | 70 |
| Seat Tube MM (st) | 410 | 440 | 608 | 510 |
| Stem Angle | ±5 | ±5 | ±5 | ±5 |
| Crank Length MM | 170 | 175 | 175 | 175 |
| Fork Rake MM (fr) | 44 | 44 | 44 | 44 |
| Front Center MM (fc) | 696 | 715 | 741 | 767 |
| Fork Length MM (fl) | 505 | 505 | 505 | 505 |
| Bar Rise MM | 4 | 4 | 4 | 4 |
| Bar Width MM | 750 | 750 | 750 | 750 |
| Backsweep | 9 | 9 | 9 | 9 |
