BMC 20 : Roadmachine X

Specifications

Frame	Roadmachine X-Tuned Compliance Concept, PF86 Bottom Bracket, Flat Mount, 12x142mm Thru axle
Tubing	AL-13 Premium Triple-butted, Hydroformed, Smoothweld Aluminium, TCC Endurance, Angle Compliance Technology
Size	47 / 51 / 54 / 56 / 58 / 61
Fork	Roadmachine X Carbon, TCC Endurance, Flat Mount, 12x100mm Thru axle
Gear	1x11
Chainwheel	SRAM Rival 1, 40T
Cassette	SRAM APEX, 11-42T
Chain	KMC X11-1
Front Derailleur	SRAM Rival
Rear Derailleur	SRAM Rival
Shifter	SRAM Rival HRD
Brake	SRAM Rival HRD-A1 w/ Centerline Rotors (160/160)
Handlebar	BMC RAB03, ergo top shape, compact bend
Stem	BMC RSM01
Seatpost	BMC RSP 03
Seat	Selle Royal 2075 HRN
Hubs	Mavic Allroad Disc UST*, Thru Axle (12mm)
Rims	Mavic Allroad Disc UST*
Tyres	WTB Exposure, 700x34c, Road TCS
Color Note	Stealth *UST Tubeless Ready (Valves Included)

Geometry

SIZE	47	51	54	56	58	61
Rider height	<166	166-174	172-180	178-186	184-192	>190
Stack mm	525	550	571	585	604	628
Reach mm	376	376	385	391	400	408
Seat tube st mm	465	490	533	548	564	600
Top tube tt‘ mm	532	539	554	564	579	594
Head tube ht mm	128	154	172	187	205	228
Seat angle sa °	73.5	73.5	73.5	73.5	73.5	73.5
Head angle ha °	70.5	70.5	71.5	71.5	72	72.5
Rear center rc mm	420	420	420	420	420	420
Front center fc mm	589	598	607	615	625	640
Wheelbase wb mm	998	1007	1016	1024	1034	1044
BB drop mm	71	71	71	71	71	71
Fork length fl mm	369	369	369	369	369	369
Fork rake fr mm	45	45	45	45	45	45
Trail mm	73	73	66	66	63	60
Crank length mm	170	170	172.5	172.5	175	175
Stem length mm	90	90	100	100	110	110
Stem angle °	+-8	+-8	+-8	+-8	+-8	+-8
Bar width mm	400	420	420	420	440	440
Bar drop mm	125	125	125	125	125	125
Bar reach mm	70	70	70	70	70	70
Post length mm	250	250	310	310	310	310
Post offset mm	15	15	15	15	15	15
