BMC 20 : Timemachine 01 DISC ONE (Size M-L)

Specifications

Frame	Timemachine 01 Disc, PF86 Bottom Bracket, Flat Mount w/ Caliper Cover, 12x142mm Thru Axle
Tubing	Aerodynamic 01 Premium Carbon
Size	S / M-S / M-L / L
Fork	Aero Premium Carbon Disc, Hinge-Design, Flat Mount w/ Caliper Cover, 12x100mm Thru Axle
Gear	2x12
Chainwheel	SRAM Force AXS 48-35T
Cassette	SRAM Force XG-1270, 10-28T
Chain	SRAM Force 12 Speeed
Front Derailleur	SRAM Force eTap AXS
Rear Derailleur	SRAM Force eTap AXS
Shifter	SRAM Force eTap AXS HRD
Brake	SRAM Force eTap AXS HRD
Handlebar	BMC Flat Cockpit / Profile T4+ Carbon Extensions
Stem	BMC Flat Cockpit
Seatpost	BMC Aero Post
Seat	Fizik Mistica
Hubs	DT Swiss ARC 1650 DICUT DB, Thru Axle
Rims	DT Swiss ARC 1650 DICUT DB Carbon 62/80mm
Tyres	Vittoria Rubino, 25mm
Color	Stealth

Geometry

SIZE	S	M-S	M-L	L
Saddle height range mm	630 - 780	660 - 850	660 - 850	700 - 880
Stack mm	480	515	515	556
Reach mm Pad stack V-Cockpit mm Pad reach V-Cockpit mm Base bar reach V-Cockpit mm Base bar drop V-Cockpit mm Pad reach Flat Cockpit mm Base bar reach Flat V-Cockpit mm Base bar drop Flat V-Cockpit mm	393 593-643 366-530 617 +85 535-610 388-474 +/- 80	377 616-665 359-522 611 +85 555-630 381-467 +/- 80	418 616-665 400-563 652 +85 555-630 422-508 +/- 80	442 656-705 417-580 669 +85 595-670 438-524 +/- 80
Seat tube st mm	495	550	550	592
Seat angle sa °	71.5 - 80.8	71.5 - 80.8	71.5 - 80.8	71.5 - 80.8
Head angle ha °	71.5	71.5	71.5	71.5
Rear center rc mm	400	400	400	393-404
Front center fc mm	580	578	619	649
Wheelbase wb mm	972	968	1009	1039
BB drop mm	58	68	68	68
Fork length fl mm	374	374	374	374
Fork rake fr mm	45	45	45	45
Trail mm	60	60	60	60
Crank length mm	170	170	170	172.5
Stem length mm	p2p	p2p	p2p	p2p
Stem angle °	p2p	p2p	p2p	p2p
Base Bar width mm	400	400	400	400
Post offset mm	27 / 9 / -9 / -29	27 / 9 / -9 / -29	27 / 9 / -9 / -29	27 / 9 / -9 / -29
Stand over height mm	755	797	797	838

Know more

Timemachine 01 Disc one มาตรฐานใหม่สำหรับรถไตรกีฬาอย่างแท้จริง

โดดเด่นด้วยเทคโนโลยีล้ำสมัย ช่วยจัดตำแหน่งให้คุณอยู่ในท่านั่งที่แอโร่ร่วมกับรถได้อย่างเหมาะสม ตอบสนองต่อการเปลี่ยนเกียร์ได้อย่างแม่นยำ ฉับไว ควบคุมการขับขี่อย่างมั่นใจในทุกสถานการณ์ อ่านเพิ่ม..คลิก

กลับ

BMC 20 : Timemachine 01 DISC ONE (Size M-L)

Specifications

Frame

Timemachine 01 Disc, PF86 Bottom Bracket, Flat Mount

Tubing

Aerodynamic 01 Premium Carbon

Size

S / M-S / M-L / L

Fork

Aero Premium Carbon Disc, Hinge-Design, Flat Mount

Gear

2x12

Chainwheel

SRAM Force AXS 48-35T

Cassette

SRAM Force XG-1270, 10-28T

Chain

SRAM Force 12 Speeed

Front Derailleur

SRAM Force eTap AXS

Rear Derailleur

SRAM Force eTap AXS

Shifter

SRAM Force eTap AXS HRD

Brake

SRAM Force eTap AXS HRD

Handlebar

BMC Flat Cockpit / Profile T4+ Carbon Extensions

Stem

BMC Flat Cockpit

Seatpost

BMC Aero Post

Seat

Fizik Mistica

Hubs

DT Swiss ARC 1650 DICUT DB, Thru Axle

Rims

DT Swiss ARC 1650 DICUT DB Carbon 62/80mm

Tyres

Vittoria Rubino, 25mm

Color

Stealth

Geometry

Saddle height range mm

630 - 780

660 - 850

660 - 850

700 - 880

Stack mm

480

515

515

556

Reach mm

393

377

418

442

Seat tube st mm

495

550

550

592

Seat angle sa °

71.5 - 80.8

71.5 - 80.8

71.5 - 80.8

71.5 - 80.8

Head angle ha °

71.5

71.5

71.5

71.5

Rear center rc mm

400

400

400

393-404

Front center fc mm

580
