BMC 20 : Teamelite 02 TWO

Specifications

Frame	Teamelite 02 - Big Wheel Concept, PF92 Bottom Bracket, 12x142mm Thru Axle
Tubing	02 Carbon, Tuned Compliance Concept, DTi
Size	S / M / L / XL
Fork	RoxShox Recon RL, Remote, 100mm
Gear	1x12
Chainwheel	SRAM NX Eagle, 32T
Cassette	SRAM NX Eagle 11-50T
Chain	SRAM NX Eagle
Front Derailleur	-
Rear Derailleur	SRAM NX Eagle
Shifter	SRAM NX Eagle
Brake	Shimano MT 500 (160/160) *
Handlebar	BMC MFB 02, 750mm
Stem	BMC MSM 02
Seatpost	BMC MSP 02
Seat	Fizik Antares R7
Hubs	Shimano Deore
Rims	Alex MD 25 **
Tyres	Vittoria Barzo G2.0 Tubless 2.25
Color Note	Ultramarine & Orange * M size spec - rotor size adjusted for some sizes ** Tubless rim strip installed, Valve included

Geometry

SIZE	XS	S	M	L	XL
rider height	<165	162-172	170-180	178-188	>188
Stack mm	599	608	618	628	638
Reach mm	377	401	426	442	458
Seat tube st mm	400	445	485	525	545
Top tube tt‘ mm	550	584	610	630	649
Head tube ht mm	90	90	100	110	120
Seat angle sa °	73.5	73.5	73.5	73.5	73.5
Head angle ha °	70	70	70	70	70
Rear center rc mm	429	429	429	429	429
Front center fc mm	625	659	685	706	725
Wheelbase wb mm	1046	1081	1107	1128	1146
BB drop mm	61	61	61	61	61
Fork length fl mm	486	506	506	506	506
Fork rake fr mm	51	51	51	51	51
Trail mm	80	80	80	80	80
Crank length mm	170	170	175	175	175
Stem length mm	60	70	70	70	80
Stem angle °	+/- 6	+/- 6	+/- 6	+/- 6	+/- 6
Bar width mm	720	720	720	720	720
Bar rise mm	4	4	4	4	4
Backsweep °	9°	9°	9°	9°	9°
Post length mm	350	350	350	400	400
Post offset mm	0	0	0	0	0
Stand over height mm	687	773	803	828	838
