BMC 21 : Teammachine ALR DISC TWO
FULL
SPECIFICATIONS
|
SKU |
Teammachine ALR DISC TWO |
|
FRAME |
Teammachine ALR Premium Alloy • Triple-butted, Hydroformed,
Smoothweld Aluminium • TCC Race compliance level • Internal Cable Routing • BSA Threaded Bottom Bracket • Flat
Mount Disc • 12x142mm thru-axle |
|
FORK |
Teammachine
ALR Carbon •
TCC Race compliance level •
Internal Cable Routing •
Flat Mount Disc • 12x100mm thru-axle |
|
GEARS |
2x11 |
|
CHAINWHEEL |
Shimano FC-RS510, 50-34T |
|
CASSETTE |
Shimano 105, 11-32T |
|
CHAIN |
Shimano 105 |
|
FRONT DERAILLEUR |
Shimano 105 |
|
REAR DERAILLEUR |
Shimano 105 |
|
SHIFTERS |
Shimano 105 |
|
BRAKES |
Shimano 105, SM-RT70 Rotors
(160 /140) |
|
HANDLEBAR |
BMC RAB 03, ergo top shape, compact
bend |
|
STEM |
BMC RSM01 |
|
SEATPOST |
Carbon D-Shape Seatpost • 15mm offset |
|
SADDLE |
VL-1489 |
|
HUBS |
CL-712 (F) / RXC-142S (R), Thru Axle |
|
RIMS |
Mavic Open Disc |
|
TIRES |
Zaffiro Pro V 25mm |
|
WEIGHT (KG) |
8.8 |
| SIZE | 47 | 51 | 54 | 57 | 60 |
| Rider Height CM | <168 | 166-174 | 172-180 | 178-188 | >186 |
| Top Tube MM (tt) | 518 | 534 | 549 | 564 | 583 |
| Wheelbase MM (wb) | 971 | 975 | 985 | 1001 | 1020 |
| Seat Angle (sa) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| Seatpost Length MM | 300 | 330 | 330 | 330 | 330 |
| Stack MM | 515 | 539 | 559 | 583 | 610 |
| Trail MM (trail) | 76 | 66 | 63 | 63 | 63 |
| Rear Center MM (rc) | 410 | 410 | 410 | 410 | 410 |
| Reach MM (reach) | 365 | 374 | 383 | 391 | 402 |
| Head Tube MM (ht) | 118 | 138 | 157 | 182 | 210 |
| Head Angle (ha) | 70.5 | 72 | 72.5 | 72.5 | 72.5 |
| BB Drop MM (drop) | 69 | 69 | 69 | 69 | 69 |
| Stem Length MM | 90 | 100 | 110 | 110 | 120 |
| Seat Tube MM (st) | 442 | 505 | 535 | 565 | 600 |
| Stem Angle | ± 8 | ± 8 | ± 8 | ± 8 | ± 8 |
| Post Offset MM | 15 | 15 | 15 | 15 | 15 |
| Crank Length MM | 170 | 170 | 172.5 | 172.5 | 175 |
| Fork Rake MM (fr) | 41.6 | 41.6 | 41.6 | 41.6 | 41.6 |
| Front Center MM (fc) | 571 | 575 | 585 | 601 | 620 |
| Fork Length MM (fl) | 369 | 369 | 369 | 369 | 369 |
| Bar Width MM | 400 | 420 | 420 | 420 | 440 |
| Bar Reach MM | 70 | 70 | 70 | 70 | 70 |
| Bar Drop MM | 125 | 125 | 125 | 125 | 125 |
