BMC 21 : Timemachine 01 DISC ONE

FULL SPECIFICATIONS

SKU

Timemachine 01 DISC ONE

FRAME

Timemachine 01 Premium Carbon with P2P positioning System

• P2P Dual-Mount Aeropost Config

• Internal Di2 battery mount

• PF86 bottom bracket

• Aerodynamic Rear Caliper Cover

• Rear Storage Box

• 12x142mm thru-axle

FORK

Timemachine 01 Premium Carbon with Hinge Design

• Aerodynamic Caliper Cover

• Flat Mount Disc

• 12x100mm thru-axle

GEARS

2x12

CHAINWHEEL

SRAM FORCE AXS 48/35T

CASSETTE

SRAM FORCE XG-1270, 10-28T

CHAIN

SRAM FORCE 12 speed

FRONT DERAILLEUR

SRAM FORCE eTap AXS

REAR DERAILLEUR

SRAM FORCE eTap AXS

SHIFTERS

SRAM FORCE eTap AXS HRD

BRAKES

SRAM FORCE eTap AXS HRD/ Rotors

HANDLEBAR

BMC Flat Cockpit / Profile T4+ carbon extensions

STEM

BMC Flat Cockpit

SEATPOST

BMC P2P Aero Post

• 62mm offset adjustment

• P2P Dual-Mount Aeropost Configuration (Triathlon & Time Trial)

SADDLE

Selle Italia Watt

HUBS

DT Swiss ARC 1650 Spline

RIMS

DT Swiss ARC 1650 Spline Carbon

TIRES

Vittoria Corsa, 25mm

TIRE CLEARANCE

27mm

WEIGHT (KG)

9.0

ASTM CLASSIFICATION

Level 1

GEOMETRY

SIZE	S	L	M-S	M-L
Rider Height CM	<170	186-196	172-180	178-188
Base Bar Drop Flat Cockpit MM	+/- 80	+/- 80	+/- 80	+/- 80
Wheelbase MM (wb)	972	1039	968	1009
Seat Angle (sa)	71.5 - 80.8	71.5 - 80.8	71.5 - 80.8	71.5 - 80.8
Stack MM	480	556	515	515
Trail MM (trail)	60	60	60	60
Rear Center MM (rc)	400	400	400	400
Pad Reach V Cockpit MM	366 - 530	417 - 580	359 - 522	400 - 563
Reach MM (reach)	393	442	377	418
Pad Stack V Cockpit MM	593 - 643	656 - 705	616 - 665	616 - 665
Head Angle (ha)	71.5	71.5	71.5	71.5
BB Drop MM (drop)	58	68	68	68
Pad Stack Flat Cockpit MM	535 - 610	595 - 670	555 - 630	555 - 630
Stem Length MM	p2p	p2p	p2p	p2p
Saddle Height Range	630 - 780	700 - 880	660 - 850	660 - 850
Stem Angle	p2p	p2p	p2p	p2p
Post Offset MM	27/ 9 / -9 / -27	27/ 9 / -9 / -27	27/ 9 / -9 / -27	27/ 9 / -9 / -27
Crank Length MM	165	172.5	170	170
Fork Rake MM (fr)	45	45	45	45
Front Center MM (fc)	580	649	578	619
Pad Reach Flat Cockpit MM	388 - 474	438 - 524	381 - 467	422 - 508
Base Bar Drop V Cockpit MM	85	85	85	85
Base Bar Reach V Cockpit MM	617	669	611	652
Fork Length MM (fl)	374	374	374	374
Base Bar Reach Flat Cockpit MM	619	670	612	653
