BMC 19 : Teammachine SLR03 ONE

BMC 19 : Teammachine SLR03 ONE

Full Specifications

FRAME Teammachine SLR03, PF86 bottom bracket
TUBING Carbon, ACE Technology, TCC Race
FORK Teammachine SLR Carbon, TCC Race
GEARS 2x11
CHAINWHEEL Shimano FC-RS510, 50-34T
CASSETTE Shimano 105, 11-32T
CHAIN Shimano 105
FRONT DERAILLEUR Shimano 105
REAR DERAILLEUR Shimano 105
SHIFTERS Shimano 105
BRAKES Shimano BR-R561
HANDLEBAR BMC RAB 03, ergo top shape, compact bend
STEM BMC RSM01
SEATPOST BMC RSP 03
SADDLE VL-1489
HUBS Shimano RS400
RIMS Mavic CXP Black
TIRES Vittoria Zaffiro Pro Slick, 25mm
FRAME MATERIAL Carbon


Geometry

SIZE 47 51 54 57 60
Rider Height cm <168 166-174 172-180 178-188 >186
Top tube tt‘ mm 520 535 550 564 583
Wheelbase wb mm 963 967 978 992 1012
Seat angle 73.5 73.5 73.5 73.5 73.5
Seatpost length mm 350 350 350 350 350
Stack mm 506 530 550 571 601
Trail mm 76 66 63 63 63
Rear Center mm 402 402 402 402 402
Reach mm 370 378 387 394 405
Head tube ht mm 108 128 148 170 201
Head angle ha ° 70.5 72.5 72.5 72.5 72.5
BB drop mm 69 69 69 69 69
Stem length mm 90 100 110 120 130
Seat tube st mm 442 505 535 565 600
Stem angle ° +/- 6 +/- 6 +/- 6 +/- 6 +/- 6
Post offset mm 15 15 15 15 15
Rear Travel 402 402 402 402 402
Crank length mm 170 170 172.5 172.5 175
Fork rake fr mm 41.6 41.6 41.6 41.6 41.6
Front center fc mm 571 575 586 600 620
Fork length fl mm 370 370 370 370 370
Bar Rise mm 70 70 70 70 70
Bar width mm 420 420 420 440 440
Bar drop mm 125 125 125 125 125
