BMC 20 : Sportelite TWO (Size L)

BMC 20 : Sportelite TWO (Size L)


Specifications

Frame

Sportelite 27.5 - BSA Threaded Bottom Bracket, 9x135mm QR

Tubing

Al-13 Butted, Hydroformed aluminium

Size

XS / S / M / L / XL

Fork

Suntour XCM-LO, 100mm

Gear

2x9

Chainwheel

Shimano FC-MT101,, 36-22T

Cassette

Sunrace 11-34T

Chain

KMC HG-53

Front Derailleur

-

Rear Derailleur

Shimano Alivio

Shifter

Shimano Alivio

Brake

Shimano BR-MT 200 (160/160) *

Handlebar

BMC MRB 03, 700mm

Stem

BMC MSM 03

Seatpost

BMC MSP 03

Seat

VL-1831

Hubs

Shimano RM-35

Rims

Jalco XCD 18

Tyres

Maxxis Ardent Race 2.2

Color

Note

Airforce Gray / Petrol Blue

* M size spec - rotor size adjusted for some sizes


Geometry

BMC20-Sporelit_Geometry


SIZEXSSMLXL
rider height
<165
162-172
170-182
180-192
>190
Stack mm
580
594
604
622
632
Reach mm
385
405
425
445
465
Seat tube st mm
380
420
460
500
540
Top tube tt‘ mm
558
586
610
635
654
Head tube ht mm
100
110
120
140
150
Seat angle sa °
73
73
73
73
73
Head angle ha °
70
70
70
70
70
Rear center rc mm
435
435
435
435
435
Front center fc mm
622
652
675
701
720
Wheelbase wb mm
1053
1083
1107
1133
1152
BB drop mm
42
42
42
42
42
Fork length fl mm
490
490
490
490
490
Fork rake fr mm
42
42
42
42
42
Trail mm
82
82
82
82
82
Crank length mm
170
170
175
175
175
Stem length mm
75
75
75
75
90
Stem angle °
6
6
6
6
6
Bar width mm
700
700
700
700
700
Bar rise mm
15
15
15
15
15
Backsweep °
9
9
9
9
9
Post length mm
350
350
400
400
400
Stand over height mm
704
744
766
779
825
